Ganpat Metal supplies Carbon Steel ASTM A333 Grade 6 Pipes for industrial piping systems designed for low-temperature service. Available in seamless and welded configurations, these pipes can be sourced according to the required material specification, pipe size, schedule, length and end finish. GM caters to industrial buyers, engineering companies, contractors, EPC companies and procurement teams seeking carbon steel pipes for specified operating conditions.
Contact Ganpat Metal with your required pipe dimensions, quantity and technical specifications to enquire about product availability and pricing.
Ganpat Metal supplies ASTM A333 Grade 6 carbon steel pipes for industrial procurement requirements where material grade, dimensions, manufacturing type and inspection documentation need to match the purchase specification.
| Specification | Details |
|---|---|
| Product | Carbon Steel ASTM A333 Grade 6 Pipe |
| Material Grade | ASTM A333 Grade 6 |
| Related Specification | ASME SA333 Grade 6, where specified |
| Manufacturing Types | Seamless and welded, subject to availability |
| Pipe Schedules | SCH 5S, 10S, 10, 20, 40S, 40, STD, 60, 80S, 80, XS, 100, 120, 140, 160 and XXS, subject to size and availability |
| Length Options | Single random, double random, required length and cut length, subject to availability |
| End Finishes | Plain end, bevelled end and threaded end, as specified |
| Dimensions | According to the applicable dimensional standard and required schedule |
| Inspection Documentation | As agreed in the purchase order |
| Supply Markets | India and international markets listed below |
The chemical composition of Grade 6 carbon steel pipes is controlled according to the specified ASTM A333 Grade 6 material requirements.
| Element | Reference Value |
|---|---|
| Carbon (C) | 0.30% maximum, subject to specification verification |
| Manganese (Mn) | Verify the applicable grade requirement |
| Phosphorus (P) | As per the applicable ASTM A333 requirements |
| Sulfur (S) | As per the applicable ASTM A333 requirements |
ASTM A333 Grade 6 pipes are supplied with the specified minimum tensile and yield strength requirements.
| Mechanical Property | Supplied Reference Value |
|---|---|
| Tensile Strength | 60,000 psi (415 MPa) minimum |
| Yield Strength, 0.2% Offset | 35,000 psi (240 MPa) minimum |
| Elongation | Confirm the applicable requirement and test basis |
Ganpat Metal handles enquiries based on the required nominal pipe size, schedule, wall thickness and length. Buyers should specify the required dimensions to confirm availability for ASTM A333 Grade 6 material.
| Parameter | Options |
|---|---|
| Schedules Available for Enquiry | SCH 5S, SCH 10S, SCH 10, SCH 20, SCH 40S, SCH 40, STD, SCH 60, SCH 80S, SCH 80, XS, SCH 100, SCH 120, SCH 140, SCH 160 and XXS |
| Note | The corresponding wall thickness varies with nominal pipe size. Confirm the required NPS or NB, schedule and quantity when requesting a quotation. |
Pipe lengths and end preparations can be specified according to fabrication, installation and project requirements.
| Parameter | Options |
|---|---|
| Length | Single Random Length |
| Length | Double Random Length |
| Length | Required Length / Cut Length (subject to availability) |
| End Finish | Plain End |
| End Finish | Bevelled End |
| End Finish | Threaded End (where applicable) |
Need a specific ASTM A333 Grade 6 size or schedule? Send your requirement to our team for availability and pricing.
Select ASTM A333 Grade 6 Pipe parameters and click the "Calculate Weight" button to reveal approximate weight.
Ganpat Metal supplies ASTM A333 Grade 6 pipes in configurations suited to different industrial piping requirements:
The construction is supplied according to the required size, wall thickness, schedule and project specification.
Pipe dimensions and theoretical weight depend on the nominal size, wall thickness and applicable dimensional standard. The dimension chart should be matched to the correct ASTM A333 Grade 6 pipe specification before being used for procurement.
For a dimension and weight confirmation, provide:
Dimensional tolerances and acceptance criteria should be confirmed against the applicable standard and purchase order.
Ganpat Metal supplies ASTM A333 Grade 6 carbon steel pipes against industrial and project requirements. Pipe selection is based on the required size, schedule, wall thickness, length and end finish.
For bulk procurement, we can process requirements based on the specified grade, dimensions, quantity and applicable inspection or documentation requirements.
The product is specified against:
The applicable specification is confirmed against the purchase order and project requirements before supply.
Inspection and testing requirements should be confirmed before order placement. The applicable standard, project specification and purchase order determine the required tests, acceptance criteria and documentation.
The availability and scope of individual tests and documents must be confirmed with Ganpat Metal. Any required inspection or certification should be agreed before the order is finalized.
ASTM A333 Grade 6 pipes are specified for piping systems involving low-temperature service, subject to the applicable design code and operating conditions.
Final material selection should consider design temperature, pressure, fluid service, applicable codes and project requirements. Suitability should be confirmed by the responsible engineering team.
Ganpat Metal accepts enquiries from industrial buyers, contractors, engineering companies and procurement teams across India. Buyers can request quotations based on the required ASTM A333 Grade 6 pipe size, schedule, manufacturing type, quantity and delivery requirements.
For bulk or project-based orders, include the applicable standard, inspection requirements and documentation details. Product availability, lead time and order-specific compliance should be confirmed before purchase.
Ganpat Metal handles international enquiries for ASTM A333 Grade 6 carbon steel pipes, subject to product availability and order requirements. Buyers can share their destination, required pipe dimensions, quantity, inspection criteria and shipping requirements to support quotation and supply planning.
India
Brazil
New Zealand
Australia
Bangladesh
Malaysia
UAE
Saudi Arabia
Oman
Egypt
Spain
Russia
Kazakhstan
For other carbon steel pipe grades, sizes and configurations, see our Carbon Steel Pipes range.
For an accurate quotation, share the following details:
| Requirement | Details to Provide |
|---|---|
| Material Grade | ASTM A333 Grade 6 or the specified equivalent |
| Pipe Type | Seamless or welded |
| Size | Required NPS or NB |
| Schedule | Required schedule or wall thickness |
| Length | Single random, double random or specified length |
| End Finish | Plain, bevelled or threaded |
| Quantity | Number of pipes or total length |
| Inspection | Required testing and documentation |
| Delivery Location | Indian destination or export country |
| Delivery Timeline | Required delivery date |
Providing complete specifications helps clarify the material, dimensions and documentation required for your order.
