BS 3059 Grade 360 Tube Manufacturer in India

Ganpat Metal supplies BS 3059 Grade 360 tubes for boiler, superheater and industrial heat-transfer equipment. These carbon steel tubes are specified under BS 3059 Part 2 for service involving elevated temperatures, with selection based on the required tube dimensions, manufacturing route, delivery condition and inspection criteria.

Buyers can submit their tube size, outside diameter, wall thickness, length, quantity and testing requirements to request a quotation for their project. Ganpat Metal is an ISO-certified and MSME-registered company serving domestic and export enquiries.

BS 3059 Grade 360 is used for steel boiler and superheater tubing where the applicable specification calls for defined mechanical properties at room temperature and specified elevated-temperature performance. Procurement documents should identify the complete standard designation, tube dimensions and required inspection tests.

Ganpat Metal handles enquiries for BS 3059 Grade 360 tubes based on project specifications and purchase schedules. For accurate quotation, include the required manufacturing type, size, wall thickness, length, end finish and any applicable IBR or additional testing requirements.

Request a Quote for BS 3059 Grade 360 Tubes

BS 3059 Grade 360 Tube Specifications

BS 3059 Grade 360 Tube Technical Data & Specifications Matrix

BS 3059 Grade 360 Tube Specifications

Specification	Details
Standard	BS 3059 Part 2
Grade	360
Material	Carbon steel
Product Type	Boiler and superheater tubes
Manufacturing Type	Seamless or welded, subject to the specified product standard and confirmed supply capability
Manufacturing Process	Cold drawn or cold finished, where specified
Outside Diameter	Confirm against the applicable standard and purchase specification
Wall Thickness	Confirm against the applicable standard and purchase specification
Length	Project-specified; confirm available range
End Finish	Plain end, beveled end or threaded, where applicable
Tube Form	Round; other forms subject to specification and confirmation
Schedules	Specify the required wall thickness or schedule and verify dimensional compatibility
Inspection	Chemical analysis, mechanical testing, dimensional inspection and other specified tests
Additional Requirements	IBR, NACE-related tests, HIC, SSC or hydrogen-service requirements where applicable and agreed

BS 3059 Grade 360 Tube Chemical Composition

Element	Grade 360 Composition
Carbon (C)	0.17% max.
Silicon (Si)	0.10–0.35%
Manganese (Mn)	0.40–0.80%
Phosphorus (P)	0.035% max.
Sulphur (S)	0.035% max.

BS 3059 Grade 360 Tube Mechanical Properties

Mechanical Property	Reference Value
Tensile Strength	360–500 MPa
Yield Strength	235 MPa min.
Elongation	24% min.

These are reference values for BS 3059 Part 2 Grade 360. Final acceptance depends on the applicable standard, test conditions, product form and material test results.

BS 3059 Grade 360 Tube Types

The product forms and descriptions relevant to a BS 3059 Grade 360 enquiry include:

Type	Description
BS 3059 Grade 360 Boiler Tubes	Tubes specified for boiler equipment.
BS 3059 Grade 360 Superheater Tubes	Tubes intended for superheater equipment when the design and specification call for this grade.
BS 3059 Grade 360 Seamless Tubes	Seamless tubing specified to the applicable standard and dimensional limits.
BS 3059 Grade 360 Welded Tubes	Welded tubing where permitted by the relevant product specification and confirmed for the order.

BS 3059 Grade 360 Tube Manufacturing and End Finishes

Manufacturing and finishing details should match the selected tube specification and the requirements of the equipment manufacturer.

Available details to specify in an enquiry include:

Seamless or welded construction, where applicable
Cold-drawn or cold-finished condition, where specified
Required tube length
Plain ends
Beveled ends, where applicable
Threaded ends, where compatible with the specified tube and connection
Dimensional and surface inspection requirements

Get Pricing for BS 3059 Grade 360 Tubes

BS 3059 Grade 360 Tube Sizes, Dimensions and Wall Thickness

Tube dimensions should be selected according to the equipment design, operating conditions and dimensional requirements stated in the purchase order. Outside diameter and wall thickness must be specified separately rather than relying on nominal size alone.

When requesting a quotation, provide:

Nominal size or specified outside diameter
Required wall thickness
Tube length and quantity
Applicable dimensional tolerances
Manufacturing type and delivery condition
End preparation
Inspection and documentation requirements

BS 3059 Grade 360 Tube Types

Boiler Tubes

Superheater Tubes

Seamless Tubes

Welded Tubes

Cold Drawn / Finished

Round Form

End Finishes: Plain End, Beveled End, Threaded End (where applicable)

BS 3059 Grade 360 Tube Applications

BS 3059 Grade 360 tubes are specified for equipment and systems where the applicable design calls for boiler or superheater tubing.

Typical application areas include:

Industrial boilers
Steam-generating equipment
Superheater assemblies
Heat-transfer equipment
Power generation installations
Process heating systems
Industrial plant equipment
Boiler and thermal equipment maintenance projects

BS 3059 Grade 360 Tube Testing and Inspection

Inspection should be defined at the enquiry stage so the supplied material and documentation meet the project's acceptance criteria.

Testing and documentation may include:

Chemical composition analysis
Tensile testing and applicable mechanical tests
Dimensional inspection
Surface examination
Flattening and flaring tests, where applicable
Non-destructive testing where specified
Material Test Certificate (MTC)
Third-party inspection, where ordered
IBR documentation or certification, where required and applicable

Why Choose Ganpat Metal for BS 3059 Grade 360 Tubes?

Product enquiries handled against the specified BS 3059 grade and standard
Technical details reviewed around tube dimensions, wall thickness and length
Options for specifying manufacturing type and end finish
Inspection and material documentation requirements considered during quotation
ISO-certified and MSME-registered company
Domestic and export enquiries accepted for industrial and project procurement

BS 3059 Grade 360 Tube Exporter from India

Ganpat Metal handles export enquiries for industrial metal products, including project-based tube specifications and documentation requirements. Buyers should share the destination, required quantity, delivery schedule and inspection documents when requesting pricing.
